Take your orthodontics
into the future
—Why Orthodontix Lab exists
The lab that engineers your treatment, not just fills your order.
Orthodontics is moving faster than ever — skeletal expansion without surgery, single-visit bracket placement, TAD-anchored mechanics that used to be impossible. We build the appliances that make it real, and we bring digital design and metal 3D printing together so the result fits, works, and delivers.
Digital by design
Every appliance is planned in software from your scans and treatment goals. You see and approve the design before a single layer is printed — no guesswork, no surprises at fit.
Metal-printed precision
Direct metal 3D printing gives us geometries, strength and fit that bent-and-soldered wirework can't match. Consistent, repeatable, and clinically robust.
— The appliance catalogue
Everything you need to run modern mechanics.
From single-visit bonding to skeletal expansion and guided traction — designed digitally, printed in metal, and fabricated to your case. If you're pushing the edge of what's possible clinically, this is the toolkit.
— Skeletal Expansion
BROLEX BMX
Compact bone-borne palatal expander with TAD anchorage resulting in pure skeletal expansion without molar tipping.
WHAT IT TREATS
Anchorage
Bone-borne with TADS
Turnaround
~2 weeks from approval
— Skeletal Expansion
HYBRID HYRAX
A very rigid palatal expander which is bone-borne & tooth borne. This offers high expansion efficiency and separates the mid-palatal suture. The use of 3D-printed molar bands eliminates the need for separating elastics.
WHAT IT TREATS
Anchorage
Bone and tooth borne
Turnaround
~2 weeks from approval
— Maxillary Expansion
RME
Traditional tooth-borne Hyrax expander printed as one very rigid framework, offering well-controlled expansion of growing patients, separating the midline suture. The use of 3D-printed molar bands eliminates the need for separating elastics.
WHAT IT TREATS
Anchorage
Tooth borne, first molars
Turnaround
~2 weeks from approval
— Expansion & Distalisation
HYBRID HYRAX DISTALISER
A rigid bone-borne & tooth borne expander with incorporated distilisation mechanics for specific cases. Once expansion is complete, the connector arm is cut to activate distilisation.
WHAT IT TREATS
Anchorage
Bone and tooth borne
Turnaround
~2 weeks from approval
— Molar distalisation/mesialisation
DISTAL SLIDER (BENESLIDER)
Skeletal anchorage to allow complex molar distilisation/mesialisation without unwanted reciprocal tooth movement. Simultaneous distilisation & mesialisation can be used to close spaces, distilise or correct midline discrepancies.
WHAT IT TREATS
Anchorage
500g NiTi springs
Attachment
Bands or bonding pads
— Molar mesialisation
MESIAL SLIDER
Skeletally anchored mesialisation which may be used for missing lateral incisors. A combination of chain elastics & 500g NiTi springs can be used to mesialise or close space without unfavourable incisor reciprocal movement.
WHAT IT TREATS
Force
Chain elastics or 500g springs
Attachment
Bands or bonding pads
— Molar distalisation
ELASTIC DISTALISER
Skeletal anchorage to achieve distilisation without unwanted incisor reciprocal movement. The use of elastics to distilise produces friction-free reverse mechanics.
WHAT IT TREATS
Force
Elastics or springs
Attachment
TADS, full- or half-bands, or bonding pads.
— Molar intrusion
MOUSETRAP
A skeletally anchored molar intruder which can be used to treat anterior open bites. By intruding the maxillary posterior teeth, the mandible could auto rotate resulting in a reduction of an anterior open bite.
WHAT IT TREATS
Anchorage
Bone borne & tooth borne.
Attachment
TADS, full- or half-bands, or bonding pads.
— Impacted Teeth
EXPOSURE FRAME
A very rigid trans palatal arch with traction arms. This gives a fixed point to apply a specific force to an impacted canine allowing complete control.
WHAT IT TREATS
Anchorage
Tooth borne TPA
Turnaround
~2 weeks from approval
— TAD Placement
DRILL GUIDE
A 3D-printed guide in validated surgical guide resin. The guide allows accurate TAD placement with 2D & 3D imaging guidance. This should be used in conjunction with the manufacturer's vertical drill stop to ensure ideal depth control. PSM predrill: 33-10914. PSM screw holder: 33-10903.
WHAT IT TREATS
Material
CE-approved resin
Compatible
Forestadent, Benefit, Dentaurum
